General Info

The Hybrid 35® is a metal roofing & siding panel that is exclusive to the Canadian market and is a long lasting, economical, exposed fastener roofing & siding solution. The Hybrid 35® metal panel installs just like our TR-936®, PR-936® & LR-936® panels. Hybrid 35® is an impressive profile, making it an exceptional addition to any residential, commercial or agricultural project! Hybrid 35® provides 35 inches of coverage and four 1 inch high major ribs. It is available in all 41 of our 40 year paint warranty colours! This panel is available in 28 gauge & 26 gauge. (Call for 24 gauge availability)

Roofing & Siding

Hybrid-35®

The Hybrid 35 Metal Panel has the look of a hidden fastener panel without the cost, & has a standing seam like appearance at regular metal pricing!

Hybrid-35 Metal Roofing & Siding | Metal Roofing & Siding Experts

Notice: Prior to beginning your installation use a check list to make sure you have everything you will need to install your metal roof. (See Sect. 1 – Pg. 12 in the complete PDF version link below)
If installing over existing shingles the roof should be strapped with minimum 1″ x 4″ strapping at 24″ centres.
Panel Installation should begin at the gable end of the roof opposite the prevailing rain bearing wind (this will help ensure that wind driven rain will not penetrate the lap).
The minimum roof slope recommended is 4″ in 12″ of rise (4/12 pitch). You can apply metal roofing to as low a pitch between 2″ in 12″ of rise and less than 4″ in 12″ of rise. This is called a low slope application and requires extra steps (see above under roof pitch).

The standard fastening and overlap patterns should be used when installing siding to ensure optimum performance. Hemmed corner flashings should be used for strong neat corners. Other flashings you will use when installing side panels are drip cap (over windows), J-Trim (around windows and doors), and door jamb flashing. You should not run siding panels all the way to the ground, and the bottom edge should be terminated on a base flashing. When the wall consists of more than one panel in each vertical row, install panels from the bottom up so water is directed away from, and not into, the lap joints. Siding panels installed horizontally should have Butyl tape or caulking applied at the vertical laps, as this will ensure weather-tite joints.

LR-936® is a long lasting, economical, exposed fastener metal roofing and siding solution. With the major rib being only 3/8” high, LR-936® is a terrific solution to cover your arch rib buildings. This profile is commonly used for residential, agricultural, or light commercial projects. LR-936® is a versatile product that can be installed over open framing or a solid substrate.

LR-936®

LR-936 metal panel is your economical choice for metal roofing & siding. This panel offers 36" of coverage and is available in 29ga, 26ga or 24ga.

LR-936 Metal Roofing and Siding | Metal Roofing & Siding Experts

PBR-1236® is a long lasting, economical, exposed fastener metal roofing and siding solution. This profile is commonly used in agricultural or commercial projects but could easily be incorporated into any residential project. PBR-1236® is a versatile product that can be installed over open framing or a solid substrate.

PBR-1236®

PBR-1236 metal panel is your economical choice for metal roofing & siding. This panel offers 36" of coverage and is available in 29ga, 26ga or 24ga.

PBR-1236 Metal Roofing and Siding | Metal Roofing & Siding Experts

PR-936® is a long lasting, economical, exposed fastener metal roofing and siding solution. This profile is commonly used for residential, agricultural, or commercial projects. PR-936® is a versatile product that can be installed over open framing or a solid substrate.

PR-936®

PR-936 metal panel is your economical choice for metal roofing & siding. This panel offers 36" of coverage and is available in 29ga, 26ga or 24ga.

PR-936 Metal Roofing and Siding | Metal Roofing & Siding Experts

Notice: Prior to beginning your installation use a check list to make sure you have everything you will need to install your metal roof.
All SNAP-TITE® panels must be installed over a solid substrate.
Panel Installation should begin at the gable end of the roof opposite the prevailing rain bearing wind (this will help ensure that wind driven rain will not penetrate the lap).
For best results a synthetic underlayment over the solid roof deck should be used to repel any moisture from the roof deck and will eliminate any potential issues with condensation.

12" Details

16" Details

Snap-Tite® 1.5 is a completely customizable hidden fastener roofing solution for your project. Available in 12″ or 16″ wide panels with a 1.5″ major rib and the minors in beads or striations, the possibilities are endless. Most commonly used in residential projects, Snap-Tite® 1.5 can easily be incorporated into any agricultural or commercial project.

Snap-Tite 1.5®

Snap-Tite 1.5 is a completely customizable hidden fastener roofing solution for your next project. So many combinations that the possibilities are endless.

Snap-Tite 1.5 (Hidden Fastener) | Metal Roofing & Siding Experts

Snap-Tite® is a completely customizable hidden fastener roofing solution for your project. Available in 12″ or 16″ wide panels with a 1″ major rib and the minors in beads or striations, the possibilities are endless. Most commonly used in residential projects, Snap-Tite® can easily be incorporated into any agricultural or commercial project.

Snap-Tite®

Snap-Tite is a completely customizable hidden fastener roofing solution for your next project. So many combinations that the possibilities are endless.

Snap-Tite (Hidden Fastener) | Metal Roofing & Siding Experts

TR-936® is a long lasting, economical, exposed fastener metal roofing and siding solution.  This profile is commonly used for residential, agricultural, or light commercial projects.  TR-936® is a versatile product that can be installed over open framing or a solid substrate.

TR-936®

TR-936 metal panel is your economical choice for metal roofing & siding. This panel offers 36" of coverage and is available in 29ga, 26ga or 24ga.
